| Parameter | Value |
| Detector | 384x288,12μm |
| Frame Rate | 50Hz |
| NETD | ≤18mk |
| Lens | 25mm(F1.0) |
| Field of View | 10.5° × 7.9° |
| Detection Range | 1280m |
| Digital Zoom | 1X/2X/4X/8X |
| Storage | 32G |
| Operation Temperature | -20°C ~ 55°C |
| Humidity Capacity | 90% |
| Dimension | 150×42×82(mm) |
| Weight | 430g |
|
Parameter |
|
|
Resolution |
384×288 |
|
|
Pixel pitch |
12μm |
|
|
Working wavelength |
8-14μm |
|
|
NETD |
≤18mK@25℃, F=1.0 |
|
|
Frame rate |
50Hz |
|
|
Lens |
|
|
Lens focal length (F number) |
25mm(F1.0) |
|
|
Field of view |
10.5°×7.9° |
|
|
Minimum imaging distance |
>2.5m |
|
|
Detection range |
1280m |
|
|
Diopter adjustment |
±5 |
|
|
Exit pupil distance |
19mm |
|
|
Internal storage |
32G (actual 27G, part of which is occupied by system operation) |
|
|
Power supply |
5V DC 2A |
|
|
Battery |
18650 with protection board, 3400mAh |
|
|
Battery working time |
≥4 hours (when WIFI and hotspot are turned off) |
|
|
USB |
USB Type-C supports charging, power supply, file transfer, and video transfer |
|
|
Working temperature |
-20~55℃ |
|
|
Storage temperature |
-30~65℃ |
|
|
Humidity |
≤90% |
|
|
IP protection grade |
IP67 |
|
|
Dimensions |
150x82x47(mm) |
|
|
Weight |
≤430g |
|
