| Parameter | Value |
| Detector | 384x288,12μm |
| Frame Rate | 50Hz |
| NETD | <17.5mK |
| Lens | 50mm (F1.0) |
| Field of View | 5.3°x3.9° |
| Detection Range | 2600m |
| Digital Zoom | 1X/2X/4X/8X |
| Storage | 32G |
| Operation Temperature | -30°C~55°C |
| Humidity Capacity | 90% |
| Dimension | 203x66x90(mm) |
| Weight | 620g |
|
Parameter |
|
|
Resolution |
384×288 |
|
|
Pixel pitch |
12μm |
|
|
Working wavelength |
8-14μm |
|
|
Laser type |
Type I Laser |
|
|
NETD |
≤17.5mK@25℃ F=1.0 |
|
|
Frame rate |
50Hz |
|
|
Lens |
|
|
Lens focal length (F number) |
50mm(F1.0) |
|
|
Field of view |
5.3°×3.9° |
|
|
Minimum imaging distance |
>5m |
|
|
Detection range |
2600m |
|
|
Optical magnification |
4.8 |
|
|
Diopter adjustment |
±5 |
|
|
Exit pupil distance |
45mm |
|
|
AMOLED |
1024×768 |
|
|
Internal storage |
32G (actual 27G, part of which is occupied by system operation) |
|
|
Power supply |
5V DC 2A |
|
|
Battery |
18650 with a protection board, 3400mAh |
|
|
Battery working time |
≥5 hours (when WIFI and hotspot are turned off) |
|
|
USB |
USB Type-C supports charging, power supply, file transfer, and video transfer. |
|
|
Working temperature |
-30~55℃ |
|
|
Storage temperature |
-40~65℃ |
|
|
Humidity |
≤90% |
|
|
IP protection grade |
IP67 |
|
|
Dimensions |
203×66×90(mm) |
|
|
Weight |
≤620g (including battery) |
|
|
Shock |
1000g/0.4ms |
|
